Máy Dập Chèn Ron Chống Nước Tự Động An Toàn WPM-078H

Name: Máy Dập Chèn Ron Chống Nước Tự Động An Toàn WPM-078H
Brand: JINGWEI
SKU: WPM-078H
Availability: InStock
Rating: 5 (1 reviews)

Mã sản phẩm: WPM-078H
Thông số kỹ thuật
Wire crimping and water seal insertion machine, Water Seal Insertion Machine, Insertion Machine
Wire range:0.3~2.5sqmm,AWG28#-AWG14#
Cutting length:45-3000mm(can be customized)
Cutting accuracy: 0.5mm+cutting lengthx0.2%
Stripping length: 0.5-8mm(can be customized)
Suitable applicator: OTP applicator, European applicator and Korea applicator
Crimping stroke:30mm(40mm for optinal)
Air pressure: 5-6kgf
Gửi yêu cầu ngay

wire crimping and water seal insertion machine, Water Seal Insertion Machine, Insertion Machine
This crimping machine is an automatic wire on both sides crimping and water seal insertion machine.
it can automatically feed the water seal by vibration plate, insert the water seal before crimping terminals.
Power: AC220v/50/60hz
Functions: Wire cut, both ends striping, one side/both sides crimping and inserting cable water seal.
Capacity: 2000pcs~3000pcs/h(L=150MM)
Wire range:0.3~2.5sqmm, AWG28#-AWG14#
Cutting length:45-3000mm(can be customized)
Cutting accuracy: 0.5mm+cutting lengthx0.2%
Stripping length: 0.5-8mm(can be customized)
Suitable applicator: OTP applicator, European applicator, and Korea applicator
Crimping stroke:30mm(40mm for optional)
Air pressure: 5-6kgf
Processing result display
